Laboratory Testing Equipment Furniture Durablity Strength Testing
Machines for Desk and Bed
This tester can be used for doing the horizontal static loading
test and also can do horizontal durability test.
Strength Durability Tester for chest desk and bed is used to test the strength and durability of each
part of furniture through each part of furniture is under one-off
or repetitive load in the normal use or wrong use condition.It is
used for testing the mechanical performance of all kinds of desk
chest and bed.
Strength Durability Tester for chest desk and bed adopts four horizontal cylinders to load edges
of the specimen repeatedly by the same force values.
After a certain test number,check the structure of
specimen,function and so on,find whether there is any damage.Then
we could know the performance and defect of products.
The tester adopts the structure of frame to design.The frame is
made of high quality industrial aluminum, beautiful and
generous.The adjustable part of the frame adopts pulley structure
to design in order to adjust the loading position to adapt to
different specifications of sample.The position handle is
convenient to locate so that the tester can improve the efficiency
The fixed block at the bottom can be adjusted freely different
position to adapt to different specifications of sample.
Strength Durability Tester for chest desk and bed adopts PLC controller to control the motion of the
tester.It is simple to operate. Force value can be adjusted through
the pressure changes in the precision pressure regulating
valve.With high precision power sensor, it can induct the force
Every load group can be adjusted to control by itself.Load force
value is stable and reliable.The loading cushion is dismountable so
that it is convenient to change different cushion to meet different
Specification of frame
2.5x2.5x2m,(L×W×H) it is made of 80x80mm aluminum
Loading force value(Max) on the theory
Force value induction
high-precision power sensor Capacity 3KNþ
0~999999 can be set
modulation of force value
pressure changes in the precision pressure regulating valve.With
high precision power sensor, it can display the force value
Source of gas
7kgf/cm^2 or More stable air source(Customer should bring your own)
