UL94 Vertical Horizontal Flammability Testing Appratus For Plastic
Fire Resistance Test
UL94 Horizontal & Vertical Flammability Tester (flammability
chamber), used to determine the flammability of plastic materials
for parts in devices and appliances. UL94 Horizontal & Vertical
Flammability Tester complies with UL HB, UL94, IEC 60695-11-10,
etc. The vedio of UL 94 flammability test procedure is attached in
this web page.
UL94 Horizontal & Vertical Flammability Tester, used to
determin the flammability of plastic materials for parts in devices
and appliances. The apparatus is supplied as a complete system
incorporating all the features necessary for ease of use safety. It
conforms to all five UL 94 horizontal and vertical burner tests and
associated ASTM international standards.
A bench mounted draft free combustion chamber having a large inside
volume of 1.0m3 and fitted with an interior light and exhaust fan
to enable simple evacuation of combustion products.
Large door and window made from toughened safety glass giving a
generous view of the specimen during a test.
Fully adjustable horizontal and vertical specimen supports.
A burner in compliance with ASTM D 5025, with simple angle
adjustment (0°, 20°, 45°) and precision gas control system
including gas flow meter, pressure regulator and pressure gauge.
Two access ports enabling easy entry to the chamber for movement of
the burner and specimen.
A burner wing tip.
Three digital test duration timers for accurate but simplified
Comply With Standards:
UL HB UL 94 V0 UL 94 V1 UL 94 V2 UL 94 5VA
UL 94 5VB UL 94 VTM-0 UL 94 VTM-1 UL 94 VTM-2 UL 94 HF-1
UL 94 HF-2 UL 94 HBF IEC 60695-11-10 IEC 60707 ISO 1210
ISO 9770 ISO 9772 ISO 9773 GB/T 2408 GB/T 8332
